suitable for heavy weight flush doors tested to BS EN 1935 Grade 14 – 160 kg
Product features
- solid brass high performance concealed bearing projection hinge
- weight carrying capacity to 160 kg
- suitable for heavy weight flush doors tested to BS EN 1935 Grade 14
- CE and UKCA marked FD30 and FD60 fire rated options
- maintenance free, 25 year performance guarantee
- security bolt and radius corner options available
Technical details
- Load capacity: 160.0 kg
- Knuckle diameter: 13.0 mm
- Overall length: 100.0 mm
- Overall width: 101.6 mm
- Material thickness: 3.5 mm
- Screws: 9.5 x 32.0 mm
- Screws (Gauge): 10.0 g
- Amount of projection: 50.0 mm
Note
- Supplied complete with pozi/slotted head brass woodscrew if required.
- Salt spray tested to over 1,000 hours.
